Recycling Plants

使用済みインクカートリッジリサイクルライン

使用済みインクカートリッジリサイクルライン、トナーカートリッジ回収プラント、プラおよび金属回収

使用済みインクカートリッジリサイクルライン、トナーカートリッジ回収プラント、プラおよび金属回収

四軸破砕機Fシリーズ

ステンレス選別機

ベルトコンベヤNSTシリーズ

   Description

使用済みインクカートリッジリサイクルライン では、顔料やプラスチックポリマーでできたプラスチック、金属、粉末を回収できます。 STOKKERMILLのトーナーカートリッジリサイクルプラントを設置することにより、トナーのリサイクル作業中に回収されたすべてのパーツ(鉄・非鉄・インク)が再利用できる様になります。 トナーのリサイクルには、トーナーへの引火・爆発の危険を避けるために特別な集塵機が必要になります。 廃トナーリサイクルラインの生産能力は、エンドユーザーが所持するトーナーの量、および処理するトーナーのサイズや種類によって異なります。

その他のリサイクル ソリューションは以下の材料に適しています。:

-       電気・電子機器廃棄物WEEE

-       アルミリサイクル

-       廃自動車・使用済み自動車

-       ハードドライブ

-       トーナー・インクカートリッジ

-       太陽パネル

-       使用済み自動車から出るフラフ

-       電線・雑線

-       PCBリサイクル

-       コーヒーカプセル

Frequently asked questions
What arethe key technologies used in a solar panel recycling plant to separatematerials?

Stokkermill solar panel recycling plant uses a combination of mechanical processes, such as crushing, shredding, and grinding, followed by air classification, vibrating screens, and magnetic separation to separate materials like silicon, glass, aluminum, and plastics. These processes ensure that each material is recovered with high purity and minimal contamination.

How does a solar panel recycling plant handle the recovery of silicon from panels?

In Stokkermill solar panel recycling plant, silicon is typically recovered through a multi-step process. After the panels are shredded and crushed, the silicon is separated from the other materials using chemical processes or thermal treatment. This recovery process is designed to maximize the yield of high-quality silicon that can be reused in new solar panels or other industries.

What is the role of glass recycling in a solar panel recycling plant?

Glass is one of the most significant components of a solar panel, and the Stokkermill solar panel recycling plant is designed to recover it efficiently. Glass is separated from the panel after the silicon and metal components are removed. The recovered glass is cleaned, processed, and repurposed for use in the production of new solar panels or as raw material for other industries such as construction or automotive.

What technologies are used for glass recovery in solar panels at a solar panel recycling plant?

Glass in solar panels is separated through an advanced mechanical process that includes crushing, vibration, and density-based separation. The Stokkermill solar panel recycling plant also uses high-frequency vibration technologies to optimize the recovery of pure glass, which is then cleaned and reused in the production of new solar panels or in other industrial applications.

Technical Specifications — LCD Screen Recycling Line

LCD recycling line render
LCD line side drawing
LCD line front drawing

General Data

  • Brand: Stokkermill
  • Model: LCD screen recycling line
  • Total weight: 2,435.7 kg

Main Dimensions

  • Total length: 5,855 mm
  • Maximum width: 4,780 mm
  • Maximum height: 3,550 mm
  • Worktop height: 1,100 mm
  • Walkway width: 2,510 mm
  • Stair width: 800 mm
  • Walkway depth: 2,270 mm
  • Footprint: ≈ 5.86 m × 4.78 m

Structure

  • Welded steel base frame (painted)
  • Walkway with safety guardrails on three sides
  • Access stairs with double handrail
  • Protective hood for cutting/press area
  • Side doors and inspection panels

Main Components

  • Cutting hood (code 061 016 A05 00)
  • Base frame (code 061 016 A06 00)
  • Walkway (code 061 016 A07 00)
  • Upper press assembly (code 061 016 A04 00)
  • Removable front/side covers for maintenance
  • Polyurethane hoses Ø 60 mm for suction/discharge

Accessories & Hardware

  • Fasteners UNI EN 24017 (M6, M8, M10, M16)
  • Washers UNI 6592 / UNI 6593
  • Self-locking nuts UNI 7473
  • Hinges ELESA CFH.50 CH-8
  • Latches Pizzato KEY F2

Functional Features

  • Machine for LCD shearing/pressing
  • Closed structure with operator safety protections
  • Top loading and rear discharge
  • Ready for external suction plant connection
  • Raised operator station for manual or semi-automatic feed

Safety

  • Anti-fall guardrails compliant with CE directives
  • Side doors with safety interlocks
  • Metal and mesh protections in access areas
  • Compliant with CE machinery safety regulations
